# Hardware recommendations

You will need a GNSS receiver and antenna in order to be able to mine rewards. onocoy is hardware-agnostic, meaning it can work with any type of receiver and antenna, provided they meet the technical requirements.

Onocoy does not sell its own hardware. Here are a few recommendations [from our partners](https://onocoy.com/partners):

<table data-card-size="large" data-view="cards" data-full-width="true"><thead><tr><th></th><th></th><th></th><th data-hidden></th><th data-hidden data-card-target data-type="content-ref"></th><th data-hidden data-card-cover data-type="image">Cover image</th></tr></thead><tbody><tr><td>GNS Electronics NTRIP-X Basestation Bundle</td><td><ul><li>Based on UniCoreComm UM980</li><li>4 frequencies supported (L1, L2, L5, E6)</li><li>Supports GPS, GLONASS, Galileo, BeiDou, QZSS and NavIC</li><li>Wifi connection</li><li><p>Example installation from vendor:</p><ul><li><a href="https://console.onocoy.com/explorer/info/DEURHIHOH3">DEURHIHOH3</a></li></ul></li></ul></td><td><a href="https://www.gns-electronics.de/product/ntrip-x-basestation-bundle/">Purchase</a></td><td></td><td><a href="https://www.gns-electronics.de/product/ntrip-x-basestation-bundle/">https://www.gns-electronics.de/product/ntrip-x-basestation-bundle/</a></td><td data-object-fit="contain"><a href="/files/mhyoRYTIXaogQFuwWNCI">/files/mhyoRYTIXaogQFuwWNCI</a></td></tr><tr><td>SparkFun RTK mosaic-X5</td><td><ul><li>Based on Septentrio mosaic-X5</li><li>5 frequencies supported (L1, L2, L5, E6, E5a+E5b)</li><li>Supports GPS, GLONASS, Galileo, BeiDou, QZSS and NavIC</li><li>Wifi or Ethernet connection </li><li><p>Example installation from vendor:</p><ul><li><a href="https://console.onocoy.com/explorer/info/USACOLNIW2">USACOLNIW2</a></li></ul></li></ul></td><td><a href="https://www.sparkfun.com/products/23748">Purchase</a></td><td></td><td><a href="https://www.sparkfun.com/products/23748">https://www.sparkfun.com/products/23748</a></td><td data-object-fit="cover"><a href="/files/cOCDAhXceLT8F7rmdG5g">/files/cOCDAhXceLT8F7rmdG5g</a></td></tr><tr><td>ArduSimple RTK Base Station </td><td><ul><li>Based on Septentrio mosaic-X5</li><li>5 frequencies supported (L1, L2, L5, E6, E5a+E5b)</li><li>Supports GPS, GLONASS, Galileo, BeiDou, QZSS and NavIC</li><li>Ethernet connection</li><li><p>Example installation from vendor:</p><ul><li><a href="https://console.onocoy.com/explorer/info/ESPZARALF1">ESPZARALF1</a></li></ul></li></ul></td><td><a href="https://www.ardusimple.com/product/rtk-base-station/">Purchase</a></td><td></td><td><a href="https://www.ardusimple.com/product/rtk-base-station/">https://www.ardusimple.com/product/rtk-base-station/</a></td><td><a href="/files/MVnySKx0M9HDgLA0yDS6">/files/MVnySKx0M9HDgLA0yDS6</a></td></tr><tr><td>Locosys GB-104B and GB-10WB </td><td><ul><li>Triple frequency</li><li>Supports GPS, GLONASS, Galileo, BeiDou, QZSS </li><li>Wifi connection (GB-10WB) or LTE connection (GB-104B)</li></ul></td><td><a href="https://www.locosystech.com/en/category/store/store-b2c.html">Purchase Locosys GB-10WB (WF+BT)</a><br><a href="https://www.locosystech.com/en/category/store/store-b2c.html">Purchase Locosys GB-104B (4G+BT)</a></td><td></td><td><a href="https://www.locosystech.com/en/product/GB-10WB.html">https://www.locosystech.com/en/product/GB-10WB.html</a></td><td><a href="/files/Ld3SoO1Tfv7nEv7yoUtT">/files/Ld3SoO1Tfv7nEv7yoUtT</a></td></tr><tr><td>GNSS Store</td><td><p><a href="https://gnss.store/blogs/elt-rtk-base/tagged/2-choosing-a-gnss-base-station#article_1000306278732">This blog article</a> helps you to choose the best receiver from GNSS Store for you. </p><p></p><p>Example installations from vendor:</p><ul><li><a href="https://console.onocoy.com/explorer/info/LVARIGRIG11">LVARIGRIG11</a> (Bynav M20)</li><li><a href="https://console.onocoy.com/explorer/info/LVARIGRIG10">LVARIGRIG10</a> (Unicore UM980)</li><li><a href="https://console.onocoy.com/explorer/info/LVARIGRIG9">LVARIGRIG9</a> (Septentrio Mosaic X5)</li></ul><p>All devices feature</p><ul><li>Wifi connection, optional PoE</li><li>All the different receiver options support GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC</li></ul></td><td><a href="https://gnss.store/products/elt0631">Purchase BYNAV M20</a><br><a href="https://gnss.store/products/elt0231">Purchase Unicore UM980</a><br><a href="https://gnss.store/products/elt0731">Purchase Septentrio Mosaic X5</a></td><td><ul><li>Triple frequency</li><li>Wifi connection, optional PoE  </li><li>Support GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC  </li></ul></td><td><a href="https://gnss.store/collections/onocoy-miners">https://gnss.store/collections/onocoy-miners</a></td><td><a href="/files/CDEisOJae45RJnVqG0Sq">/files/CDEisOJae45RJnVqG0Sq</a></td></tr><tr><td>onoLink Miner</td><td><ul><li><strong>Triple-frequency GNSS receiver</strong> (GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC)</li><li>Equipped with the <strong>advanced Unicore UM980 chip</strong>, offering state-of-the-art GNSS performance for maximum precision and reliability</li><li><strong>Wi-Fi connectivity</strong> for flexible and easy network integration</li><li><strong>Over-the-Air (OTA) firmware updates</strong> ensuring device security, improved performance, and effortless maintenance</li><li>Optimized for seamless integration into professional DePIN setups and high-performance GNSS networks</li><li>Robust hardware designed for continuous, reliable operation in diverse environments</li></ul><p>Example installations from vendor: <a href="https://console.onocoy.com/explorer/info/DEULOWWOL1">DEULOWWOL1</a>,  <a href="https://console.onocoy.com/explorer/info/DEUBADWER1">DEUBADWER1</a></p></td><td><a href="https://onolink.io/product/onolink-miner/">Purchase</a></td><td></td><td><a href="https://onolink.io/product/onolink-miner/">https://onolink.io/product/onolink-miner/</a></td><td><a href="/files/0RWar3UUwSqqW0VnsuPm">/files/0RWar3UUwSqqW0VnsuPm</a></td></tr><tr><td>Kindhelm’s LOCANOS Base Station</td><td><p></p><ul><li>4 frequencies supported (L1, L2, L5, E6)</li><li>Supports GPS, GLONASS, Galileo, BeiDou, QZSS and NavIC</li><li>Wired interfaces: Ethernet, USB-C</li><li>Wireless interfaces: Wi-Fi, Bluetooth<br>4G cellular modem (optional)<br>UHF radio modem (optional)</li></ul></td><td><a href="https://shop.kindhelm.com/products/locanos-base-station-lite">Purchase</a></td><td></td><td></td><td data-object-fit="contain"><a href="https://framerusercontent.com/images/7lCLZ2uklrVBP1nMNnzNfXvDmE.png">https://framerusercontent.com/images/7lCLZ2uklrVBP1nMNnzNfXvDmE.png</a></td></tr><tr><td>Kindhelm’s LOCANOS Base Station Fixed</td><td><p></p><ul><li>4 frequencies supported (L1, L2, L5, E6)</li><li>Supports GPS, GLONASS, Galileo, BeiDou, QZSS and NavIC</li><li>Wired interfaces: Ethernet, USB-C</li><li>Wireless interfaces: Wi-Fi, Bluetooth<br>4G cellular modem (optional)<br>UHF radio modem (optional)</li></ul></td><td><a href="https://shop.kindhelm.com/products/locanos-base-station-fixed">Purchase</a></td><td></td><td></td><td data-object-fit="contain"><a href="https://framerusercontent.com/images/M4uSxBDfpedo3AOXI9WRq5WWH3c.png">https://framerusercontent.com/images/M4uSxBDfpedo3AOXI9WRq5WWH3c.png</a></td></tr><tr><td>Autosteer Base Station</td><td><p></p><ul><li>Based on Septentrio mosaic-X5</li><li>5 frequencies supported (L1, L2, L5, E6, E5a+E5b)</li><li>Supports GPS, GLONASS, Galileo, BeiDou, QZSS and NavIC</li><li>Ethernet connection</li></ul></td><td><a href="https://www.autosteer.cc/produkt/onocoy-rtk-base-station-mosaic-x5-high-performance/">Purchase</a></td><td></td><td></td><td data-object-fit="contain"><a href="https://framerusercontent.com/images/ba4cxsNSfE4Ls6iZoeqwF3MIq0.png">https://framerusercontent.com/images/ba4cxsNSfE4Ls6iZoeqwF3MIq0.png</a></td></tr><tr><td>Sixents G20</td><td><p></p><ul><li>4 frequencies supported (L1, L2, L5, E6)</li><li>Supports GPS, GLONASS, Galileo, BeiDou, QZSS and NavIC</li><li>Ethernet connection</li><li>Wifi connection</li></ul></td><td><a href="https://www.qdnavi.com/product/g20/">Purchase</a></td><td></td><td></td><td data-object-fit="contain"><a href="https://framerusercontent.com/images/EcPPUG6MuhnGPxZqqg4XE9l7nME.png">https://framerusercontent.com/images/EcPPUG6MuhnGPxZqqg4XE9l7nME.png</a></td></tr></tbody></table>

Some remarks if you want to DIY or bring your own:

* For maximizing rewards, a triple- or quad band GNSS receiver that supports all of the major constellations (GPS, Galileo, BeiDou and GLONASS) is required.
* GNSS receivers with a lower number of supported frequency bands (e.g. only L1+L2, or L1+L5) will receive rewards, albeit at a lower level than triple/quad band receivers
* A high quality GNSS antenna which supports the receiver’s frequency bands.
* The GNSS receiver should either directly support connection to an Ethernet/Wifi network, or be connected to a host (Raspberry Pi, ESP32, or equivalent) that acts as a bridge.&#x20;
* The receiver must have "NTRIP Server" functionality.
* Please note that GNSS receivers only receive signals, hence, there is no additional electromagnetic transmission originating from operating the receiver.
